Three way intelligentpolishing machine -- Rw-spMJ-02
- Model
- RW-SPMJ-02
Item specifics
- Model
- RW-SPMJ-O2
- Power
- 8.5 kw
- Dimensions(Length x Width x Height]
- Grinding equipment: 2108*1200*1807Control cabinet: 600*450*1120mm
- Weight
- Approximately 500kg
- Belt Length
- 2100*50;2100*100x2mm
- Effective Grinding Distance
- 50mm
- Brand of Electrical Componentsin the Control System
- Delixi; Chint
Review
Description
Three Way Intelligent Polishing Machine
The Three Grinding Head Automatic Grinding Machine is designed for workpieces requiring simultaneous grinding of upper and lower surfaces as well as edges. Fully automated from workpiece clamping to completion, it combines versatility with high productivity.
Request a Quote →Performance Characteristics
Width ≤100mm Simultaneous Grinding
Grinds upper and lower surfaces plus edges in one setup.
R-Angle Up to R30mm
Outer corner grinding for any angle with height ≤100mm, achieves R1~R30mm.
3 Grinding Heads, 7 Combinations
Heads work independently or together — one machine serves seven functions.
Weld Seam & Surface Brushing
Ideal for finishing weld seams and creating uniform brushed surfaces.
Technical Parameters
| Model | RW-SPMJ-02 |
|---|---|
| Power | 8.5 kW |
| Dimensions (Grinding Unit) | 2100 × 1200 × 1807 mm |
| Dimensions (Control Cabinet) | 600 × 450 × 1120 mm |
| Weight | Approx. 500 kg |
| Belt Length(s) | 2100×50 mm; 2100×100 mm (x2) |
| Effective Grinding Distance | 50 mm |
| Electrical Components | Delixi / Chint |
Applicable Scope
- Combined grinding of edges, corners, and small flat surfaces
- Small/medium workpieces and solid wood furniture
- Doors, windows, kitchenware, electrical cabinets
- Sports equipment and general metal fabrication
Why Choose the RW-SPMJ-02?
Maximize throughput with multi-surface grinding in one automatic cycle. The flexible three-head design adapts to complex part geometries.
Ready to Automate Multi-Surface Grinding?
Contact us to discuss how the RW-SPMJ-02 can streamline your production.
Get a Quote →Email: info@metalworkmaster.com | WhatsApp: +86 15156147667
